Specifications:
1. Model: XCE145P12E
2. Actuator Type: Top plunger (pin-type)
3. Contact Configuration: SPDT (1NO + 1NC)
4. Rated Voltage: 250V AC (typical)
5. Rated Current: 10A (resistive load)
6. Ingress Protection: IP65 or higher (confirm with datasheet)
7. Operating Force: ~5β10 N (varies by version)
8. Pretravel / Overtravel: ~2mm / 1mm
9. Mechanical Durability: >10 million operations
10. Electrical Durability: >500,000 operations
11. Mounting Type: Panel or surface mount
12. Housing Material: Metal alloy or high-strength thermoplastic
13. Dimensions: Approx. 75mm Γ 28mm Γ 30mm
14. Weight: ~150 grams
