Specifications:
Processor: Broadcom BCM2711, 1.5 GHz quad‑core Cortex‑A72
Memory: 8 GB LPDDR4‑3200 SDRAM
Video & Audio Outputs: 2× micro‑HDMI (4Kp60 max), MIPI DSI/CSI
Storage: microSD slot (SDR104)
Networking: 1× Gigabit Ethernet, 2.4/5 GHz Wi‑Fi, Bluetooth 5.0 BLE
USB Ports: 2× USB 3.0, 2× USB 2.0
GPIO: 40‑pin full‑sized header
Power Input: USB‑C, 5 V ⎓ 3 A (max 15 W)
Dimensions: 85 mm × 56 mm × 17 mm
Weight: Approximately 46 g
Operating Temperature: 0 °C to +50 °C
