Specifications:
Display Type: TFT-LCD (Transmissive)
Screen Size: 9.0 inches (diagonal)
Resolution: WSVGA – 1024 × 600 pixels
Aspect Ratio: 16:9
Color Depth: 262K / 16.7M colors
Backlight Type: LED (Edge-lit, White)
Brightness: ~400–500 cd/m² (typical)
Contrast Ratio: ~500:1 to 700:1 (typical)
Viewing Angle: Horizontal: ±70° / Vertical: ±50° (typical)
Interface: LVDS, 1-channel, 6-bit or 8-bit options
Response Time: ~20–30 ms (typical)
Power Supply Voltage: 3.3V (logic), 9–12V (backlight driver, external)
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
Non-returnable
₹7,850.00 ₹10,640.00
