RF & Communication Specifications:
Frequency Band:
868 MHz ISM band (also supports 860–870 MHz tuning via software)
Modulation Techniques:
LoRa™ Spread Spectrum
FSK, GFSK, OOK (configurable)
Output Power:
Programmable up to +20 dBm with power amplifier
High-efficiency PA for long-distance communication
Communication Range:
Up to 10 km (line-of-sight) in ideal conditions
Typically 2–5 km in urban/obstructed environments
Data Rate:
Configurable between 0.018 kbps to 37.5 kbps (LoRa)
Up to 300 kbps (FSK)
Sensitivity:
As low as –148 dBm with LoRa modulation
Non-returnable
₹450.00 ₹600.00
