Specifications
Panel Type: a‑Si TFT‑LCD, transmissive
Resolution: 640 (RGB) × 480 pixels
Interface: Digital 6‑bit RGB input
Backlight: External (typically CCFL or LED inverter required)
Viewing Angle: Wide (approx. 160° horizontal/vertical)
Brightness: Typically around 400 cd/m²
Contrast Ratio: Approx. 250:1
Drive Type: Chip‑on‑Glass driver included
Mounting: Standard 4‑corner screw holes
Dimensions: ~160 mm × 120 mm outline (active area ~130 mm × 98 mm)
Operating Temperature: Generally 0 °C to +50 °C
Compliance: RoHS‑compliant, lead‑free
Non-returnable
₹12,000.00 ₹15,000.00
