Specifications:
Display Size: 10.1 inches (25.65 cm) diagonal
Resolution: 1280 × 800 pixels (WXGA)
Aspect Ratio: 16:10
Pixel Pitch: ~0.1695 (H) × 0.1695 (V) mm
Pixel Density: ~149 PPI
Color Depth: 262K / 16.2M (6-bit + Hi-FRC)
Display Mode: a-Si TFT, normally white, transmissive
Brightness: ~200–250 cd/m² (typical)
Contrast Ratio: ~500–700:1
Viewing Angles: ~85°/85°/85°/85° (L/R/U/D)
Response Time: ~8–10 ms (typical)
Backlight Type: White LED, edge-lit
Backlight Lifetime: ~15,000–20,000 hours
