Specification:
Display Size: 4.3 inches (diagonal)
Resolution: 480 (RGB) × 272 pixels (WQVGA)
Aspect Ratio: 16:9
Display Type: TFT LCD, Normally White, Transmissive
Touch Panel: Projected Capacitive (PCAP), integrated
Brightness: Typically 400–500 cd/m²
Contrast Ratio: ~500:1
Viewing Angles (L/R/U/D): ~70° / 70° / 60° / 60° (typical)
Response Time: ~25 ms
Backlight Type: White LED
Interface Type: 24-bit Parallel RGB TTL
Surface Treatment: Anti-glare, hard-coated
Operating Temperature Range: -20°C to +70°C
Storage Temperature Range: -30°C to +80°C
