LG. Philips LB070WV8-SL02 LCD DISPLAY

The LG.Philips LB070WV8-SL02 is a 7.0-inch a-Si TFT-LCD module featuring an 800(RGB)×480 (WVGA) resolution with a sharp 133 PPI pixel density, delivering crisp and detailed visuals ideal for embedded and industrial applications requiring vibrant displays.

The module’s active area measures 152.4 mm (W) × 91.44 mm (H), providing an optimal viewing space balanced with a compact outline of 170 × 106.3 × 10.7 mm, facilitating integration into space-constrained devices.

This display boasts a high luminance of 450 cd/m² and a strong contrast ratio of 800:1 (Typ.) (TM), ensuring excellent readability and vivid image quality under a wide range of ambient lighting conditions.

Thanks to its IPS technology with a-Si TFT-LCD structure, operating in Normally Black, Transmissive mode, the panel delivers wide viewing angles of 89° (all directions, Min.) (CR≥10), producing consistent color and contrast from any perspective.

Supporting 16.7 million colors with 60% NTSC coverage, the LB070WV8-SL02 provides rich, lifelike images suitable for detailed graphical interfaces and high-quality visual presentations.

The module connects via a LVDS (1 channel, 8-bit) interface with a 30-pin connector for reliable, high-speed data transmission, and incorporates a WLED backlight with an integrated driver, offering a long operational life of up to 50,000 hours.

Designed for robust industrial use, it operates efficiently within a wide temperature range of -30°C to 80°C, and can be safely stored between -30°C and 85°C, making it a versatile and durable choice for challenging environments.
