Specification:
1. Display & Resolution:5.7-inch a-Si TFT-LCD, 320 × 240 pixels (QVGA), 4:3 aspect ratio, transmissive mode.
2. Color & Pixel Pitch:262K colors (6-bit), approx. 0.36 × 0.36 mm.
3. Brightness & Contrast:~500 cd/m² typical brightness, ~500:1 contrast ratio.
4. Viewing Angle & Response Time:~130° horizontal / 110° vertical viewing angles, ~25 ms response time.
5. Backlight, Interface & Durability:White LED (~50,000 hrs), TTL 18-bit RGB Parallel interface, anti-glare hard-coating (2H), operating -30°C to +85°C, storage -40°C to +90°C.
