The Lora1276C1-868 is a high-performance low-power wireless transceiver module operating in the 868 MHz ISM band, designed for long-range, low-data-rate communication using LoRa® modulation technology. Developed around the Semtech SX1276 RF chip, the module provides robust wireless communication in the presence of interference and over long distances, thanks to the spread spectrum and forward error correction features inherent to LoRa.
This compact module is ideal for IoT, smart agriculture, remote monitoring, home automation, industrial telemetry, and sensor networks. It provides high sensitivity, long-range capability, and reliable data transmission with ultra-low power consumption, making it suitable for battery-operated systems.
Key Features:
LoRa Modulation Technology for ultra-long-range spread spectrum communication.
Operating Frequency: 868 MHz ISM band (Europe-compliant).
Low Power Consumption:
High Sensitivity: Down to -139 dBm
Transmission Power: Adjustable, up to +20 dBm (100 mW)
Communication Range: Up to 5–10 km (open area, line of sight)
Data Rate: 0.018 kbps to 37.5 kbps (LoRa mode)
Interface: UART or SPI
Built-in PA (Power Amplifier) and LNA (Low Noise Amplifier)
Forward Error Correction with Interleaving
Robust Anti-interference Performance
Compact Form Factor for easy integration
