The Sharp LJ089MB2S01 LCD Module8.9″ display features a 640×400 resolution with a pixel density of 84 PPI, providing a decent level of clarity. The active area measures 191.9 mm (W) × 119.9 mm (H), and the outline dimensions are 246 mm (H) × 158 mm (V) × 26.5 mm (D), making it compact yet effective for various small-sized applications.
With a luminance of 60 cd/m², it is suited for use in low-light environments where high brightness isn’t required. The viewing angle of 80/80/80/80 degrees ensures consistent visibility from different directions (CR≥10), although the display lacks specific contrast ratio data and response time information.
This display utilizes Electroluminescent (EL) technology, offering monochrome support without additional color or backlight features. It operates on 5.0/12.0V power, making it versatile for different power requirements. The display can function in temperatures ranging from -5°C to 55°C during operation and can be stored in -40°C to 80°C environments.
