Specifications:
Display Size & Resolution: 10.1-inch a-Si TFT, 1366 × 768 pixels (HD+), 16:9 aspect ratio, normally white, transmissive.
Pixel & Color: Pixel pitch ~0.1875 × 0.1875 mm, ~149 PPI, 262K / 16.2M colors (6-bit + Hi-FRC).
Brightness & Contrast: ~200–220 cd/m² typical brightness, ~500:1 contrast ratio.
Viewing Angle & Response Time: 45° left/right, 15° up, 35° down (typical), 8–12 ms response time.
Backlight, Interface & Dimensions: White LED edge-lit (~15,000–20,000 hrs), 40-pin LVDS (1-channel, 6-bit), anti-glare hard coating (3H), outline dimensions ~229.46 × 149.1 × 3.6 mm, active area 223.57 × 125.39 mm.
