Specifications:
Model: YXL 402030
Battery Type: Lithium Polymer (LiPo)
Nominal Voltage: 3.7V
Capacity: 320mAh
Energy: ~1.18Wh
Charge Voltage: 4.2V (max)
Discharge Cutoff Voltage: ~3.0V
Standard Charge Current: 0.2C (64mA)
Max Discharge Current: Typically 1C–2C (320mA–640mA)
Dimensions: 4.0mm (thickness) × 20mm (width) × 30mm (length)
Weight: ~7 grams
Operating Temperature: 0°C to 60°C (charging), –20°C to 60°C (discharging)
Cycle Life: 300–500 cycles (to 80% capacity retention)
