Specification:
Display Size: 10.4 inches (diagonal)
Resolution: 800 × 600 pixels (SVGA)
Aspect Ratio: 4:3
Display Type:TFT LCD, transmissive, normally white
Brightness: 700 cd/m² (typical)
Contrast Ratio: 600:1 (typical)
Color Depth: 16.7 million colors (24-bit RGB)
Viewing Angles: 80° (Left/Right), 60° (Up), 80° (Down)
Pixel Pitch: ~0.264 mm (H) × 0.264 mm (V)
Active Area: 211.2 mm (W) × 158.4 mm (H)
Outline Dimensions: 243 mm (W) × 184 mm (H) × ~10 mm (D)
Backlight Type: White LED backlight (edge-lit)
Backlight Lifetime: ≥ 50,000 hours
Signal Interface: 18-bit or 24-bit RGB parallel interface
Input Voltage: 3.3V (logic supply)
Touch Panel: Not included (can be paired with resistive or capacitive touch)
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
