Specification:
Display Type: TFT-LCD
Screen Size: 10.1 inches (diagonal)
Resolution: WUXGA – 1920 × 1200 pixels
Aspect Ratio: 16:10
Pixel Pitch: Approx. 0.1125 mm × 0.1125 mm
Color Depth: 16.7 million colors (8-bit)
Backlight: White LED (edge-lit), low power, long lifespan
Interface: MIPI DSI (4 lanes)
Viewing Angle: Wide (typically ≥ 85° in all directions)
Brightness: Typically 350–400 cd/m²
Contrast Ratio: ~800:1 to 1000:1
Response Time: ~25 ms (typical)
