Specifications:
Cellular Standard: LTE Cat NB2 (NB-IoT)
Frequency Bands: B1, B2, B3, B4, B5, B8, B12, B13, B17, B18, B19, B20, B25, B28, B66, B70, B85
Form Factor: 17.7 mm × 15.8 mm × 2.0 mm (LCC package)
Weight: ~1.8 grams
Operating Voltage: 2.2 V to 4.3 V (typical 3.3 V)
Transmit Power: +23 dBm ±2 dB
Current Consumption:
Idle: ~67 mA
TX: Up to 330 mA
Power Saving Mode: ~0.8 µA
Data Rate:
Uplink: Up to 158.5 kbps
Downlink: Up to 127 kbps
Interfaces: UART, GPIO, I2C, SPI, ADC, PWM, USIM
Operating Temperature: -40°C to +85°C
Compliance: RoHS, CE, FCC, GCF, PTCRB
Non-returnable
₹699.00 ₹1,000.00
