RF AND WIRELESS MODULEQUECTEL MODULES LC86LICMD - Gnss/gps Iot Module with Integrating Patch Antenna
LC86LICMD - Gnss/gps Iot Module with Integrating Patch Antenna
LC86LICMD - Gnss/gps Iot Module with Integrating Patch Antenna
LC86LICMD - Gnss/gps Iot Module with Integrating Patch Antenna
LC86LICMD - Gnss/gps Iot Module with Integrating Patch Antenna

LC86LICMD - Gnss/gps Iot Module with Integrating Patch Antenna

  1. Constellations Supported:

    • GPS L1 C/A

    • GLONASS L1

    • BeiDou B1I

    • Galileo E1 (available in LC86L(C) version)

    • QZSS

  2. Tracking Channels: 26

  3. Acquisition Channels: 11

  4. Position Fixing: Cold start: ~32s, Hot start: ~1s

  5. Sensitivity:

    • Tracking: –167 dBm

    • Acquisition: –148 dBm

  6. Update Rate: 1 Hz (default), up to 10 Hz supported

Non-returnable
₹650.00 ₹1,000.00
Product Details

The Quectel LC86LICMD is an ultra-compact GNSS module designed for IoT applications, featuring an integrated patch antenna. It supports multiple GNSS constellations, including GPS, GLONASS, BeiDou, Galileo (LC86L(C) variant), and QZSS, providing robust positioning capabilities.


Type: GPS/GNSS Receiver Module Integrated Antenna: Yes (ceramic patch antenna) GNSS Support: GPS, GLONASS, QZSS Interface: UART Features: High sensitivity, low power consumption Fast cold start and TTFF Compact form for IoT and wearable applications Applications: Asset tracking, IoT, navigation devices
