Specification:
Display Size: 9.0 inches (diagonal)
Display Type: TFT LCD, Transmissive
Resolution: 800 (RGB) × 480 (WVGA)
Aspect Ratio: 15:9
Brightness: Typically 400 cd/m²
Contrast Ratio: 500:1 (typical)
Viewing Angles (L/R/U/D): 65° / 65° / 55° / 60°
Response Time: ~25 ms
Display Mode: Normally White
Backlight Type: White LED
Surface Treatment: Anti-glare (AG)
Touch Panel: Not included (optional external touch panel can be added)
Interface: 24-bit Parallel RGB (TTL)
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
