Specifications:
Display Size: 10.2 inches (diagonal)
Display Type: TFT LCD (Thin Film Transistor Liquid Crystal Display)
Resolution: 800 (RGB) × 480 pixels (WVGA)
Aspect Ratio: 15:9
Brightness: Typically 400 cd/m² (candela per square meter)
Contrast Ratio: 500:1
Viewing Angle: 70° (Left) / 70° (Right) / 50° (Up) / 70° (Down)
Display Mode: Normally White, Transmissive
Response Time: Approximately 25 milliseconds
Backlight: White LED backlight for consistent brightness
Interface: TTL (RGB 24-bit), suitable for direct connection to many microcontrollers and embedded systems
Surface Treatment: Anti-glare coating to reduce reflections and improve visibility
Touch Panel: Not included (display only)
Operating Temperature Range: -20°C to 70°C
Storage Temperature Range: -30°C to 80°C
