Specifications:
Display Type: a-Si TFT-LCD (Active Matrix)
Screen Size: 12.1 inches (diagonal)
Resolution: 1024 × 768 (XGA)
Aspect Ratio: 4:3
Color Depth: 262K/16.2M colors (6-bit/8-bit via FRC)
Brightness: ~400 cd/m² (typical)
Contrast Ratio: ~700:1
Viewing Angle: ±70° horizontal, ±60° vertical (typical)
Surface Treatment: Anti-glare (AG), Hard coating (3H)
Backlight Type: White LED (long-life, edge-lit)
Backlight Lifetime: ~50,000 hours (typical)
Interface: 1-channel 6-bit LVDS
Power Supply Voltage: 3.3V (logic), ~12V (backlight driver, if external)
