      BATTERY MANAGEMENT SYSTEM 3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality
      3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality
      3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality
      3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality
      3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality
      3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality
      3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality

      3S 11.1V 10A 18650 Lithium Battery Overcharge And Over-current Protection board-Good Quality

      Specifications:
      1. Battery Configuration: 3S (3 cells in series)
      2. Input Voltage (charging): 12.6V max
      3. Nominal Battery Voltage: 11.1V
      4. Continuous Discharge Current: 10A
      5. Peak Current Protection: ~13A (varies by version)
      6. Overcharge Detection Voltage: ~4.25V ± 0.05V per cell
      7. Over-discharge Detection Voltage: ~2.50V ± 0.05V per cell
      8. Overcurrent Protection Threshold: ≥10A
      9. Short-circuit Protection: Yes (auto recovery or manual reset type)
      10. Balance Function: Not included (basic protection board)
      11. PCB Dimensions: Approx. 45mm × 35mm × 3mm
      12. Weight: ~8 grams

      Non-returnable
      ₹62.00 ₹70.00
      Product Details

      This high-quality 3S (3-cell series) Battery Protection Board is specifically designed for 11.1V lithium-ion battery packs using 18650 cells. It provides comprehensive protection against overcharge, over-discharge, overcurrent, and short-circuits, ensuring battery safety and longevity. The compact design and reliable performance make it ideal for use in DIY battery packs, portable electronics, e-bikes, power tools, and solar-powered systems.

      Features:
      - Supports 3-series 18650 Li-ion cells (11.1V nominal)
      - 10A continuous discharge current capacity
      - Overcharge protection, over-discharge protection, short-circuit protection, and overcurrent protection built-in
      - High conversion efficiency and low heat generation
      - Compact and durable PCB design
      - Suitable for DIY battery packs, robotics, and small-scale energy storage
