The display offers a typical luminance of 400 cd/m² and a contrast ratio of 600:1, ensuring crisp image quality even in brightly lit settings. Furthermore, the display offers wide viewing angles—80° horizontally and up to 60° vertically (CR≥10)—which help maintain consistent readability from multiple directions. As a result, it proves especially suitable for user-facing interfaces or shared display setups.
Built with a TN panel using a-Si TFT-LCD technology, the display operates in a normally white, transmissive mode. To enhance durability and visual clarity, it features an antiglare surface and a 3H hard coating that minimize reflections and resist scratches.
Moreover, the panel supports both 262K and 16.2 million colors, covering 55% of the NTSC gamut. This level of color depth ensures that graphics, indicators, and text remain distinct and reasonably vibrant, even in utilitarian display environments.
In terms of performance, the module delivers a response time of 10 ms (rise) and 25 ms (fall), making it suitable for general UI tasks, low-motion video, and real-time system feedback. For connectivity, it uses an LVDS (1 channel, 6/8-bit) interface via a 20-pin connector—offering reliable high-speed data transmission with good noise immunity, which is ideal for embedded system integration.
Technical Precautions :-
It is a front polarizer. It may damaged. Please be cautious. Don't scratch it.
Always turn off the power supply when you are inserting or disconnecting it from the input connector.
Wipe off water drop immediately as it may cause discoloration or spots.
Please handle with great care. It may broken or cracked if dropped or bumped on hard surface.
Do not try to open or modify the module assembly.
At the insertion or removal of the Signal Interface Connector do not rotate or tilt the Interface Connector of the TFT Module. It may damage the panel.
Severe temperature condition may result in different luminance, response time.
