DEVELOPMENT BOARDORANGE PIORANGE PI BOARD Orange Pi 5 plus 4GB
Orange Pi 5 plus 4GB
Orange Pi 5 plus 4GB
Orange Pi 5 plus 4GB
Orange Pi 5 plus 4GB
Orange Pi 5 plus 4GB
Orange Pi 5 plus 4GB

Orange Pi 5 plus 4GB

Specifications:

  1. CPU: Rockchip RK3588 (8-core: 4× Cortex-A76 @ 2.4GHz + 4× Cortex-A55 @ 1.8GHz)

  2. GPU: ARM Mali-G610 MP4 with OpenGL ES 3.2, Vulkan 1.2, OpenCL 2.2

  3. RAM: 4GB LPDDR4/4x (non-upgradable, onboard)

  4. Storage:
    – 1× microSD slot
    – 1× eMMC module socket
    – 1× M.2 M-Key PCIe 3.0 x4 slot for NVMe SSD

  5. Video Output:
    – 2× HDMI 2.1 (up to 8K@60fps)
    – 1× USB Type-C with DP1.4 support

  6. Network:
    – Dual 2.5GbE RJ45 Ethernet ports

  7. Wireless (optional): via M.2 E-Key slot (for Wi-Fi 6/Bluetooth module)

  8. USB Ports:
    – 2× USB 3.0 Type-A
    – 2× USB 2.0 Type-A
    – 1× USB Type-C (power & data)

  9. Expansion:
    – 40-pin GPIO header (Raspberry Pi compatible layout)
    – 1× MIPI-CSI (camera), 1× MIPI-DSI (display)

  10. Audio: Via HDMI, Type-C, or external USB sound card

  11. Power Supply: 5V/5A via USB Type-C or GPIO

  12. Operating System Support: Android 12, Ubuntu, Debian, Buildroot, and others

  13. Dimensions: Approx. 100mm × 70mm

  14. Weight: ~65 grams

  15. Operating Temperature: 0°C to +60°C

  16. Applications: AI development, multimedia systems, network storage, edge computing, robotics

  17. Compliance: RoHS, CE, FCC certified

Non-returnable
₹10,400.00 ₹12,000.00
Product Details

The Orange Pi 5 Plus (4GB RAM variant) is a high-performance single-board computer (SBC) based on the powerful Rockchip RK3588 processor, featuring an octa-core CPU and integrated ARM Mali-G610 MP4 GPU. Engineered for advanced AI, multimedia, and computing tasks, it supports 8K video playback, PCIe 3.0, and dual 2.5GbE Ethernet. With rich I/O including multiple USB 3.0 ports, dual HDMI outputs, and M.2 slots for SSD or Wi-Fi/BT modules, it is ideal for developers building AI applications, media centers, NAS systems, edge computing platforms, or robotics projects. The 4GB LPDDR4 RAM variant provides a balance of performance and cost for moderate to demanding workloads.


• Powered by Rockchip RK3588 octa-core processor (4× Cortex-A76 + 4× Cortex-A55)
• Integrated ARM Mali-G610 MP4 GPU for advanced graphics and AI acceleration
• 4GB LPDDR4/4x RAM (soldered onboard) for responsive multitasking
• Dual HDMI 2.1 outputs support 8K@60fps video playback
• PCIe 3.0 x4 M.2 slot (NVMe SSD support) and M.2 E-Key for wireless modules
• Dual 2.5GbE Ethernet ports for high-speed networking and server applications
• USB 3.0, USB 2.0, and USB Type-C ports for versatile peripheral connectivity
• GPIO headers for hardware expansion, compatible with various HATs
• Supports Android 12, Debian, Ubuntu, and other Linux distributions
• Ideal for AIoT, robotics, media servers, industrial automation, and learning platforms
