Specifications:
1. Model: Z-15GQ-B
2. Actuator Type: Hinge lever (short type)
3. Rated Voltage/Current:
• 250VAC / 15A
• 125VDC / 0.6A
4. Contact Configuration: SPDT (1NO + 1NC)
5. Contact Type: Snap-action
6. Operating Force: Approximately 1.96 N (200 gf)
7. Max. Operating Frequency: 120 operations/min (mechanical), 30 ops/min (electrical)
8. Insulation Resistance: ≥100 MΩ at 500VDC
9. Dielectric Strength: 1,000 VAC (between terminals)
10. Mechanical Life: Up to 10 million operations
11. Electrical Life: Up to 500,000 operations (at rated load)
12. Operating Temperature: –10°C to +80°C
13. Mounting: Panel mounting with screws
14. Housing Material: Resin + metal actuator
15. Protection Rating: IP40
16. Weight: ~50–70 grams
