Specifications:
Battery Type: Lithium Thionyl Chloride (Li-SOCl₂)
Nominal Voltage: 3.6V
Capacity: ~2.4Ah (2400mAh)
Size: AA (14.5mm diameter x 50.5mm length)
Weight: Approx. 17g
Operating Temperature: -55°C to +85°C
Max Continuous Current: 100mA
Max Pulse Current: 200mA
Self-discharge Rate: <1% per year at 20°C
Shelf Life: Up to 10–15 years
Terminals: Axial, standard button-top, or customized options
