7.0-inch diagonal TFT LCD panel Resolution: 1024 × 600 pixels (WXGA) Display Mode: Transmissive, Normally White Brightness: Typically 500 cd/m² Contrast Ratio: Approximately 800:1 Viewing Angle: 85° horizontal / 75° vertical Response Time: ~25 ms (rise + fall) Color Depth: 16.7 million colors (8-bit) Interface: 24-bit RGB TTL Backlight: White LED, edge-lit Operating Temperature: –20 °C to +70 °C Storage Temperature: –30 °C to +80 °C Surface Treatment: Anti-glare, 3H hard coating RoHS Compliant
High-Definition Visuals: Offers WXGA resolution (typically 1280×800) for crisp, detailed image reproduction.
Compact 7-inch Size: Optimized for space-constrained applications like handheld devices, dashboards, and compact HMIs.
Bright LED Backlighting: Ensures excellent brightness for both indoor and outdoor use, with long lifespan and energy efficiency.
Anti-Glare Coating: Enhances readability in high ambient light or direct sunlight.
Wide Temperature Range: Built to operate in challenging environments, supporting industrial-grade temperature tolerance.
Durable Design: Suitable for rugged applications such as factory automation, vehicle systems, and embedded control panels.
Wide Viewing Angles: TFT technology enables consistent image quality from multiple angles, enhancing user experience.
