Specifications:
Pressure Range: 20 – 250 kPa absolute (2.9 – 36.3 psi)
Supply Voltage: 4.85 – 5.35 V (nominal 5.1 V)
Supply Current: ~7 mA (max 10 mA)
Output Voltage (0 kPa): ~0.13–0.27 V
Output Voltage (250 kPa): ~4.83–4.97 V
Sensitivity: ~20 mV/kPa
Accuracy: ≤ ±1.5% full-scale span (0–85 °C)
Response Time: ~1 ms
Warm-up Time: ≤ 20 ms
Operating Temperature: −40 °C to +125 °C
Maximum Pressure: 1000 kPa (safe up to 10× rated pressure)
Pinout (Unibody):
• Pin 1: VOUT
• Pin 2: GND
• Pin 3: VCC
• Pins 4–6: No-connect
