Specification:
Display Size: 4.3 inches (diagonal)
Resolution: 480 (RGB) × 272 pixels (WQVGA)
Aspect Ratio: 16:9
Display Type: TFT LCD, Normally White, Transmissive
Brightness: Typically 400–500 cd/m²
Contrast Ratio: ~500:1 (typical)
Viewing Angle: 70° (Left/Right), 60° (Up), 60° (Down)
Response Time: ~25 ms
Backlight Type: White LED
Interface: 24-bit Parallel RGB (TTL)
Surface Treatment: Anti-glare, hard-coated
Touch Panel: (Optional in some variants)
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
