A chip-on-board (COB) graphic LCD featuring a 240×64 dot matrix STN panel with a blue transmissive display. It operates at 5 V and uses an 8‑bit parallel interface, typically driven by controllers like T6963C, RA6963, NT7086E, or RA8822. Ideal for embedded systems, industrial instrumentation, and DIY electronics requiring clear, low-power visual output.
Features
240×64 pixel resolution (graphical dot matrix)
STN blue transmissive display with LED backlight
COB construction for compact and robust integration
8‑bit parallel interface (6800 or 8080 series)
Standard driver ICs: T6963C, RA6963, NT7086E, or RA8822
Backlight colors: white, blue, or yellow-green
Viewing angle: 6:00 orientation
Temperature range: –20 °C to +70 °C (operating), –30 °C to +80 °C (storage)
Supports negative or positive mode (default blue negative)
