Specifications:
1. Sensor Type: MS5837-30BA (TE Connectivity)
2. Pressure Range: 0 – 30 bar (3000 mbar)
3. Resolution: ~0.2 mbar (approx. 2mm water level)
4. Communication Interface: I2C (Fast Mode: 400kHz)
5. Supply Voltage: 1.5V – 3.6V DC
6. Current Consumption: ~0.6 μA in idle, ~1.5 mA during conversion
7. Output: 24-bit pressure and temperature readings
8. Temperature Range: -20°C to +85°C
9. Accuracy: ±1 mbar (typical)
10. Dimensions: Approx. 25mm × 15mm × 3mm
11. Weight: Approx. 4g
12. Mounting: Onboard headers / solder pads
13. Applications: Depth sensing, underwater vehicles, pressure monitoring systems, diving computers, environmental research
Non-returnable
₹2,900.00 ₹3,500.00
