Mitsubishi AA065VD13 LCD display

Specification:

Manufacturer: Mitsubishi
Model: AA065VD13
Display Size: 6.5 inches
Display Type: TFT LCD with active matrix technology for consistent image quality
Resolution: 640 × 480 pixels (VGA) – standard clarity for embedded graphical interfaces
Brightness: 400 cd/m² (typical) – sufficient for indoor and semi-industrial lighting environments
Contrast Ratio: 600:1 – ensures balanced and detailed contrast for text and image display
Viewing Angles: 80° left/right, 70° up/down – wide-angle visibility for flexible mounting and operation
Interface: LVDS – enables high-speed, low-interference image signal transmission
Backlight: Long-life LED – energy-efficient and reliable for continuous usage in industrial systems

Non-returnable

₹18,840.00 ₹22,000.00

Available Offer

Product Details

The Mitsubishi AA065VD13 LCD Module delivers a 640×480 VGA resolution with 122 PPI, ensuring sharp and detailed visuals. Its active area of 132.48(W)×99.36(H) mm offers a compact yet effective display.

The 1300 cd/m² brightness makes it ideal for outdoor or high-light environments, while the 600:1 contrast ratio enhances image clarity. With 80° viewing angles horizontally and 60° vertically, it ensures consistent display quality from various angles.

The TN, Normally White, Transmissive mode provides natural color representation. It supports 262K colors at 40% NTSC, making it suitable for industrial and professional applications.

The CMOS (1 ch, 6-bit)31-pin connector ensures reliable signal transmission, while the 60Hz frame rate maintains smooth performance. Powered by 3.3V, it features a dual-string WLED backlight with an impressive 100,000-hour lifespan.

Its -30°C to 80°C operating range makes it highly durable in extreme conditions.
